Name: Integral DUAL OLED Surface Roughness Tester SRT5030
Brand: HUATEC
Price: 1 USD

Model Number : SRT5030

Payment Terms : L/C,T/T,Western Union

Display Accuracy : 0.01μm

Battery : 3.7V Lithium Rechargeable battery

MOQ : 1set

Packaging Details : in carton

Supply Ability : 50 sets per month

Optional Parameter : Ra, Rz, Rq, Rt

Dimensions in mm : 110×81×32

Delivery Time : 5-7 days after payment

Light weight : 150g

Brand Name : HUATEC

Certification : ISO,CE

Place of Origin : China

Product name : Roughness Tester

Contact Now

Integral DUAL OLED Surface Roughness Tester SRT5030

Features

Dual OLED displays to suit your applications;

2 start keys ( the left key & the right key) to satisfy the different using habits;

Mobile app compatible to get the higher accuracy, convenient to be used in a small space

ARM processor to offer higher speed, low power consumption and fast accurate measurement.

Light weight of 150g, easy & convenient to use.

Main Technical Specifications
Optional Parameter	Ra, Rz, Rq, Rt
Measuring Range(μm)	Ra, Rq: 0.05 ~ 10.0; Rz, Rt: 0.1 ~ 50
Sampling Length(mm)	0.25/ 0.80/ 2.5
Evaluation Length(mm)	1.25/ 4.0/ 5.0
Running Length(mm)	6
Display Accuracy	0.01μm
Display Deviation	±(7-10)%
Display Repeatability	＜12%
Stylus Radius	10 μm±1 μm
Static Contact Force	≤ 0.016N
Force Change Rate	≤ 800N/m
Sensor Lead Pressure	≤ 0.5N
Battery	3.7V Lithium Rechargeable battery
Dimensions in mm	110×81×32
Weight	150g

Standard Delivery

Integral DUAL OLED Surface Roughness Tester SRT5030
