0410-BA Portable Wireless Bendable Flat Panel Detector with 102.4 × 256mm Active Area and 180s Max Window Time

Model Number : 0410-BA

Certification : ISO, CE, GOST

Place of Origin : China

Brand Name : HUATEC

Receptor Type : TFT / PD matrix panel

Contact Now

0410-BA Portable Wireless Bendable Flat Panel Detector
Product Overview

The 0410-BA is a portable wireless bendable flat panel detector based on amorphous silicon sensor technology, specifically designed for pipeline inspection, security check, power applications, and related fields.

Technical Specifications
Receptor TypeTFT / PD matrix panel
ScintillatorGos
Active Area102.4 × 256mm
Effective Pixel Matrix1024 × 2560
Pixel Pitch100 μm
Max. Window Time≤180 seconds
Frame Rate1 fps
AD Conversion16 bit
Trigger ModeAED / Software
Energy Range40-450KV
Limited Bending Radius≥80 mm
ECU Data InterfaceWired: GigE
Wireless: 802.11, 2.4G/5G
Dimensions155 × 364 × 28 mm (FPD)
144 × 118 × 30.5 mm (ECU)
Weight≤2.5 kg (FPD only)
≤3.5 kg (with ECU)
Power Supply & Battery
Adapter InputAC 100-240V, 50-60Hz
Adapter OutputDC 24V, 2.7A
Power Dissipation<16 W
Battery Working Time6.5 hours
Charging Time4.5 hours
Key Features
  • 10 × 25 cm² bendable active area
  • 100μm pixel pitch with 16-bit ADC for superior image detail
  • Robust wired and 5G wireless data interface
  • Up to 180 second X-ray exposure window
Environmental Specifications
Temperature (Operating)-20 to 50°C
Temperature (Storage)-20 to 50°C
Humidity30-70% RH (non-condensing)
Ingress ProtectionIP67
