AWS-DSC UT Calibration Block Shear Wave Distance Sensitivity Refracted Angle Beam Index Calibration Ultrasonic Testing Reference Block

Name: AWSDSC UT Calibration Block Shear Wave Distance Sensitivity Refracted Angle Beam Index Calibration Ultrasonic Testing Reference Block
Brand: HUATEC
Price: 1 USD

$Quality AWS-DSC UT Calibration Block Shear Wave Distance Sensitivity Refracted Angle Beam Index Calibration Ultrasonic Testing Reference Block for sale$ $Quality AWS-DSC UT Calibration Block Shear Wave Distance Sensitivity Refracted Angle Beam Index Calibration Ultrasonic Testing Reference Block for sale$

Model Number : DSC

MOQ : 1pc

Packaging Details : Carton packaging box

Supply Ability : 10pcs/month

Standard : ASTM E164 and AWS 6.16. 1B.

Certification : CE

Brand Name : HUATEC

Payment Terms : T/T,Paypal

Delivery Time : 3-5 working days

Dimensions : 1. 0”thick. Metric version available.

Place of Origin : China

Material : Carbon steel

Contact Now

AWS-DSC UT Calibration Block Shear Wave Distance Sensitivity Refracted Angle Beam Index Calibration Ultrasonic Testing Reference Block

Standard: ASTM E 164-2013

The AWS-DSC Block measures distance, sensitivity, refracted angle and beam index calibration for angle beam transducers, per AWS and ASHTO requirements.

	ASTM E164 and AWS 6.16. 1B
Dimensions	1. 0”thick. Metric version available

Applications:

Calibration of transverse and longitudinal wave distance, setting determination of the sound beam point of incidence, angle of propagation and sensitivity.

*AWS-type block used for shear wave distance and sensitivity calibration.Contains a 1.0" radius opposite a 3.0" radius. The 3.0”radius includes a 0.375* deep x .032”wide radiused slot. Also contains a 0° reference point for checking exit point on wedge, and a .125”diameter through hole and corresponding markings at 45°, 60 and 70° for measuring actual refracted angle.

$AWS-DSC UT Calibration Block Shear Wave Distance Sensitivity Refracted Angle Beam Index Calibration Ultrasonic Testing Reference Block$
